./beamlevel --wall

Calculate geometric low-beam reference marks. Use the OEM value when available; otherwise the application can recommend a slope based on headlight height and auto-leveling.

[01]

INPUT / MEASUREMENTS

EDITABLE

distance to wall

A1

From the headlights to the wall; minimum recommended distance is 5 m. · 1–25 m

headlight center height

A2

From the ground to the headlight bulb. · 20–160 cm

distance between headlight centers

A3

Between the headlight bulbs. · 30–220 cm

slope source

App's recommendationwhen the OEM value is unavailable Enter manuallyvalue shown on the headlight or in the manual

Does the vehicle have auto-leveling headlights?

Yes No Not sure

“Not sure” uses the recommendation for a vehicle without auto-leveling.

slope used

A4

The recommendation is a fallback; the OEM value on the headlight, vehicle, or in the manual takes priority.

[02]

OUTPUT / WALL MARKERS

READY

target_height 65.0 cm # from floor

center_offset 60.0 cm # on each side

PREVIEW / WALL — front view
